Name: HD Wheels Clutch Satin Black
SKU: 4509803774037
Availability: InStock

Description

CLUTCH Features & Specifications

• Ultra Lightweight 10 Spoke Design with Various Lip Sizes.

• Load Rating. 690kg / 1521lbs for each wheel.

• Industry Leading 3 Year Finish Warranty.

• Lifetime Structural Warranty.

• Free Shipping & Install Hardware on Sets of 4 Orders Only.

─────────────────────────────────────────────────────

Clutch Mounting Directions

• Sizes: 15×6.5, 16×7.0, 17×7.5, 18×7.5 = FRONT MOUNT ( FACE UP )

• Sizes: 18×9.0, 20×8.5, 20×10.0 = REVERSE MOUNT ( FACE DOWN )

Clutch Weights:

15×6.5 =15lbs | 16×7.0 = 17lbs | 17×7.5 = 19lbs |18×7.5 = 21lbs

18×9.0 = 22lbs |20×8.5 = 32lbs | 20×10.0 = 33lbs

Additional information

mycustom

Size > Bolt Pattern > Offset > Back Spacing > CB#15×6.5 > 4×100/4×114.3 > et40mm > 5.3 in > 73.1mm>15×6.5 > 5×100/5×114.3 > et40mm > 5.3 in > 73.1mm>16×7.0 > 5×100/5×114.3 > et40mm > 5.6 in > 73.1mm>17×7.5 > 5×100 > et35mm > 5.6 in > 73.1mm>17×7.5 > 5×112 > et35mm > 5.9 in > 73.1mm>17×7.5 > 5×114.3 > et35mm > 5.9 in > 73.1mm>18×7.5 > 5×100 > et35mm > 5.6 in > 73.1mm>18×7.5 > 5×112 > et42mm > 5.9 in > 73.1mm>18×7.5 > 5×114.3 > et20mm > 5.1 in > 73.1mm>18×7.5 > 5×114.3 > et42mm > 5.9 in > 73.1mm>18×7.5 > 5×120 > et35mm > 5.6 in > 73.1mm>18×9 > 5×112 > et45mm > 6.8 in > 73.1mm>18×9 > 5×114.3 > et25mm > 6.0 in > 73.1mm>18×9 > 5×114.3 > et40mm > 6.6 in > 73.1mm>18×9 > 5×1114.3 > et45mm > 6.8 in > 73.1mm>18×9 > 5×120 > et40mm > 6.6 in > 73.1mm>20×8.5 > 5×114.3 > et20mm > 5.6 in > 73.1mm>20×8.5 > 5×114.3 > et35mm > 6.1 in > 73.1mm>20×8.5 > 5×120 > et35mm > 6.1 in > 73.1mm>20×10 > 5×114.3 > et25mm > 6.5 in > 73.1mm>20×10 > 5×114.3 > et42mm > 7.2 in > 73.1mm>20×10 > 5×120 > et42mm > 7.2 in > 73.1mm
